PV37W105C01B00

厂牌: BOURNS
产品描述: 1MΩ ±10% 250mW ±150ppm/℃ 线性 通孔安装 6.7mm(高度)
供应商型号: PV37W105C01B00
供应商: Master
标准整包数: 100
BOURNS 电位器及其他可变电阻器 PV37W105C01B00

PV37W105C01B00概述

    # PV37 Series Trimmer Potentiometers
    Product Introduction
    The PV37 Series from Bourns is a high-quality line of multiturn, sealed trimmer potentiometers designed for various applications requiring precise control over electrical resistance. These potentiometers are available in both top and side adjustment configurations, making them versatile for different mounting scenarios. The PV37 Series is commonly used in electronic circuits where adjustable resistance values are needed, such as in audio equipment, industrial controls, and automotive electronics.
    Key Features:
    - Multiturn Design: Offers 12 turns per revolution, providing fine-tuning capability.
    - Cermet Construction: Ensures stability and long-term reliability.
    - Sealed Mechanism: Protects against environmental contaminants like dust and moisture.
    - Standoffs: Allow thorough cleaning of PCB boards during manufacturing processes.
    - RoHS Compliant: Meets environmental regulations, making it eco-friendly.
    Technical Parameters
    | Parameter | Value |

    | Power Rating | 0.25 W (at 85°C) |
    | Number of Turns | 12 (Effective Rotation Angle)|
    | Resistance Range | 10 Ω to 1 MΩ |
    | Resistance Tolerance | ±10% |
    | Temperature Coefficient | ±150 ppm/°C |
    | Operating Temperature | -55°C to +125°C |
    These potentiometers are suitable for environments ranging from extreme cold (-55°C) to high heat (+125°C), making them ideal for rugged conditions.
    Product Features and Advantages
    The PV37 Series offers several distinct advantages over similar products:
    1. Precision Adjustability: With 12 turns per revolution, users can achieve highly accurate adjustments, which is crucial in precision applications.
    2. Durability and Reliability: The cermet material ensures stability even under harsh conditions, while the sealed design protects against external elements.
    3. Compatibility: The ability to choose between top and side adjustments provides flexibility in circuit design and integration.
    4. Environmental Compliance: Being RoHS compliant makes these potentiometers environmentally friendly and safe for use in global markets.
    Application Case Studies and Usage Tips
    Typical Applications:
    - Audio Equipment: Used in volume controls and tone controls.
    - Industrial Controls: Essential in machinery where precise resistance settings are required.
    - Automotive Electronics: Found in various control units due to their robustness and reliability.
    Usage Recommendations:
    - Ensure proper mounting to prevent damage during soldering or mechanical stress.
    - Use the recommended soldering method (wave soldering) to maintain integrity.
    - Regularly test resistance values post-installation to ensure no drift has occurred.
    Compatibility and Support
    The PV37 Series is compatible with standard wave soldering techniques, facilitating easy integration into existing manufacturing lines. Bourns provides comprehensive support through documentation and customer service, ensuring that users have access to necessary resources for optimal performance.
    Common Issues and Solutions
    | Problem | Solution |

    | Drift in Resistance Values | Re-calibrate using high-precision equipment |
    | Poor Solder Joint | Re-solder ensuring correct temperature profile|
    | Physical Damage | Replace affected component |
    Conclusion and Recommendation
    The PV37 Series potentiometers are an excellent choice for applications requiring precise and reliable resistance adjustments. Their durable construction, wide operating range, and compatibility make them a standout option in the market. Given their robust features and proven track

PV37W105C01B00参数

参数
电阻值 1MΩ
精度 ±10%
额定功率 250mW
温度系数 ±150ppm/℃
锥度 线性
额定电压 -
长*宽*高 6.7mm(高度)
安装方式 通孔安装
零件状态 在售
包装方式 散装
