MS3126F16-26S

产品分类: 圆形连接器
厂牌: AMPHENOL
产品描述: Bayonet Lock,Female Sockets,Plug 26pin Aluminum 7.5A 金 橄榄绿,褐色 导线安装,自由悬挂,通孔安装 64.21mm(长度)
供应商型号: MS3126F16-26S
供应商: Master
标准整包数: 1
AMPHENOL 圆形连接器 MS3126F16-26S

MS3126F16-26S概述

    Amphenol® 97 Series Miniature Cylindrical Connectors: Technical Overview and Application Insights
    Product Introduction
    Amphenol® 97 Series Miniature Cylindrical Connectors represent a versatile family of connectors designed for both industrial and military applications. These connectors are widely used in sectors such as instrumentation, monitoring equipment, machine tool automation, communications, geophysics, robotics, oil and petrochemical industries, rail/mass transit, and aerospace/military. The series is notable for its compact size, providing twice the number of contacts compared to standard connectors in half the space. This product line is UL and CSA recognized and includes both solder and crimp termination options.
    Technical Parameters
    - Operating Voltage: Up to 1000 VAC (RMS) at sea level.
    - Operating Temperature: From -55°C to +125°C.
    - Contact Material: Machined from low-loss copper alloy and gold-plated for corrosion resistance and extended shelf life.
    - Dielectric Strength: High-resilient inserts provide excellent insulation.
    - Environmental Sealing: Achieved using the grommet and clamp design.
    - Finish Options: Olive drab cadmium, anodic coating.
    - Service Classes: Meets MIL-DTL-26482 Series 1, service classes E, F, and P.
    Product Features and Advantages
    1. Compact Design: Twice the contact density in half the size.
    2. Versatile Termination Options: Solder and crimp contacts allow flexible integration into various systems.
    3. Bayonet Coupling: Quick and secure connection mechanism.
    4. Sealed Environment: Ensures reliability in harsh conditions.
    5. Wide Range of Configurations: Multiple shell styles and insert patterns cater to diverse application needs.
    Application Cases and Usage Tips
    Amphenol® 97 Series connectors are ideal for environments requiring reliable and durable connections. Common applications include:
    - Industrial Automation: Machine tool and factory automation setups where connectors must withstand repeated cycles and dust.
    - Military Use: Rugged conditions demand connectors with exceptional sealing and durability.
    - Communications: High-speed data transmission in critical infrastructure.

    Usage Suggestions:
    - For high-vibration environments, ensure proper strain relief and coupling mechanisms are implemented.
    - When dealing with high-power applications, consider the thermal management capabilities of the connectors.
    Compatibility and Support
    Amphenol® 97 Series connectors are compatible with various devices and systems, particularly those adhering to MIL-DTL-26482 standards. The company provides extensive support through its global network, offering technical assistance and maintenance services. Customers can access product literature and catalogs via the Amphenol website.
    Common Issues and Solutions
    1. Poor Connection Quality: Ensure correct termination and check for contamination on contact surfaces.
    2. Water Ingress: Verify proper installation of grommets and clamps.
    3. Electrical Noise: Implement EMI filter connectors to mitigate interference.
    Conclusion and Recommendation
    Amphenol® 97 Series Miniature Cylindrical Connectors excel in their field due to their compact design, robust performance, and broad compatibility. They are recommended for applications requiring high-density connectivity in demanding environments. Users seeking reliable, efficient, and adaptable connectors should consider integrating these products into their systems.
    For more information or specialized inquiries, contact Amphenol Industrial Operations directly.

MS3126F16-26S参数

参数
端接 -
额定电流 7.5A
外壳材料 Aluminum
针脚数 26pin
触头镀层 - 配接
类型 Bayonet Lock,Female Sockets,Plug
颜色 橄榄绿,褐色
长*宽*高 64.21mm(长度)
安装方式 导线安装,自由悬挂,通孔安装
应用等级 仪表级,军用级,工业级,航天级
零件状态 在售
包装方式 散装
