686108183822

产品分类: FFC/FPC连接器
厂牌: WURTH
产品描述: Wurth Elektronik 1mm间距8p FPC插座 FPC连接器, WR-FPC系列, 单排, 表面, SMT
供应商型号: 2749026
供应商: 海外现货
标准整包数: 1
WURTH FFC/FPC连接器 686108183822

686108183822概述

    WR-FPC SMT ZIF Vertical Electronic Component: Comprehensive Overview
    Product Introduction
    The WR-FPC SMT ZIF Vertical is a cutting-edge electronic connector designed specifically for Surface Mount Technology (SMT) applications. Primarily used in flexible printed circuit (FPC) connections, this connector supports Zero Insertion Force (ZIF) technology, ensuring easy and secure connectivity without damaging delicate circuits. Its primary function is to provide reliable and efficient data transmission between PCBs and FPCs in various electronic devices.
    Key Applications:
    - Consumer electronics (smartphones, tablets)
    - Wearable devices
    - Communication equipment
    - Industrial automation systems
    - Medical devices
    Technical Parameters
    The following table summarizes the critical technical specifications of the WR-FPC SMT ZIF Vertical:
    | Parameter | Value | Unit |
    |
    | Pitch | 1 | mm |
    | Number of Pins | 8
    | Length (L) | 14.8 | mm |
    | Length (L1) | 13.5 | mm |
    | Length (L2) | 9.2 | mm |
    | Recommended Land Pattern | 7 | mm |
    | Durability | 20 | Mating Cycles |
    | Operating Temperature | -25 to +85 | °C |
    | Rated Current | 1 | A |
    | Working Voltage | 125 | V (AC) |
    | Withstanding Voltage | 250 | V (AC) |
    | Contact Resistance | 30 | mΩ max. |
    | Insulation Resistance | 100 | MΩ min. |
    Additional properties include:
    - Insulator Material: PA6T
    - Insulator Flammability Rating: UL94 V-0
    - Contact Material: Phosphor Bronze
    - Solder Tabs: Brass
    Product Features and Advantages
    1. Zero Insertion Force Design: Simplifies the assembly process and minimizes potential damage to fragile circuits.
    2. High Durability: Capable of supporting up to 20 mating cycles without degradation.
    3. Fire Safety: UL94 V-0 rated materials ensure excellent flame retardancy.
    4. Wide Operating Temperature Range: Designed to perform reliably from -25°C to +85°C.
    5. Excellent Electrical Performance: Maintains low contact resistance and high insulation resistance.
    Application Case Studies and Usage Suggestions
    The WR-FPC SMT ZIF Vertical is ideally suited for applications requiring compact and robust connectors, such as smartphones, tablets, and wearable gadgets. For instance:
    - In smartphones, it facilitates efficient data transmission between mainboards and display panels.
    - In wearable devices, its small form factor ensures seamless integration into tight spaces.
    Usage Tips:
    - Always follow proper soldering procedures as per the specified profile to prevent damage.
    - Ensure proper storage conditions to maintain optimal performance.
    - Avoid prolonged exposure to sunlight or extreme temperatures during handling.
    Compatibility and Support
    This product is compatible with standard SMT processes and adheres to international standards like IPC/JEDEC J-STD-020E. Würth Elektronik provides comprehensive support, including detailed packaging specifications and a precaution guide available online. Their commitment to quality ensures compatibility with their full suite of components and tools.
    Common Issues and Solutions
    Below are some common problems users may encounter along with their solutions:
    1. Problem: Poor contact due to improper soldering.
    - Solution: Follow the recommended reflow profile strictly.

    2. Problem: Damage during insertion/removal.
    - Solution: Use gentle force when m

686108183822参数

参数
外壳颜色 乳白色
板上高度 3.25mm
间距 1mm
额定电流 1A
连接器/触头类型 底部
扁平柔性类型 FFC
触头镀层
端接 焊盘
针脚数 8pin
安装方式 贴片安装
零件状态 在售
包装方式 卷带包装
