LTC1663IMS8#TR

产品分类: 其他放大器
厂牌: ANALOG DEVICES
产品描述:
供应商型号: CY-LTC1663IMS8#TR
供应商: Avnet
标准整包数: 1
ANALOG DEVICES 其他放大器 LTC1663IMS8#TR

LTC1663IMS8#TR概述

    Product Overview: LTC1663 10-Bit Rail-to-Rail Micropower DAC
    The LTC1663, manufactured by Linear Technology (now part of Analog Devices), is a versatile 10-bit voltage output DAC with true buffered rail-to-rail output voltage capability. It offers an array of features designed to enhance performance in a wide range of applications, including industrial process control, arbitrary function generation, and battery-powered data conversion products.
    Technical Parameters
    The following technical specifications outline the core capabilities of the LTC1663:
    | Parameter | Minimum | Typical | Maximum | Unit |

    | Resolution | - | 10 | - | Bits |
    | Differential Nonlinearity (DNL) | ±0.2 | ±0.75 | - | LSB |
    | Integral Nonlinearity (INL) | ±0.5 | ±0.5 | ±2.5 | LSB |
    | Supply Voltage (VCC) | 2.7 | - | 5.5 | V |
    | Operating Current (ICC) | 60 | 100 | - | μA |
    | Shutdown Mode Current (ISD) | 10 | 24 | - | μA |
    | Output Impedance | 65 | - | 500 | Ω |
    | Output Voltage Span | 0V | - | VCC | V |
    | Settling Time | 30 | - | - | μs |
    | Power Supply Rejection Ratio (PSRR) | - | ±0.4 | - | LSB/V |
    Key Features:
    - True Rail-to-Rail Output: Ensures maximum efficiency in voltage swing.
    - Selectable Reference: Can operate with either an internal bandgap reference (2.5V) or the supply voltage.
    - Micro Power Consumption: 60 μA operating current for efficient power management.
    - Dual Buffering: Supports simultaneous updates across multiple devices.
    - Wide Supply Range: Operates within 2.7V to 5.5V.
    - Power-On Reset: Ensures initial output stability at 0V.
    Product Features and Advantages
    The LTC1663 stands out due to its compact design, robust performance, and energy efficiency. Its primary advantages include:
    1. Rail-to-Rail Output Capability: Ensures minimal distortion and higher resolution across a broader voltage range.
    2. Versatile Reference Selection: Allows flexibility in selecting the reference based on application needs.
    3. Ultra-Low Power Consumption: Ideal for battery-operated systems requiring prolonged operation.
    4. High Reliability: Features a power-on reset mechanism and high PSRR for robust performance in noisy environments.
    5. Small Footprint: Available in 5-lead SOT-23 and 8-lead MSOP packages, minimizing space usage in circuit designs.
    Application Scenarios and Usage Recommendations
    The LTC1663 finds extensive application in systems requiring precise analog output control, such as industrial automation, battery-powered instruments, and test equipment. Some practical use cases include:
    1. Industrial Automation: Implementing controlled processes with high precision, ensuring tight tolerance in outputs.
    2. Automotive Systems: Utilizing low-power solutions in automotive electronics where reliability and space are critical.
    3. Test and Measurement Equipment: Serving as a high-resolution digital-to-analog converter for complex signal generation tasks.
    Usage Suggestions:
    - Always select the appropriate reference type (internal or external) based on the application's requirements.
    - Use pull-up resistors or current sources on the SDA and SCL lines to ensure proper communication with the host system.
    - Ensure that the system operates within the recommended supply voltage and temperature range for optimal performance.
    Compatibility and Support
    The LTC1663 integrates seamlessly with other I²C-based devices, allowing for easy implementation in multi-device systems. Analog Devices provides comprehensive documentation, software

LTC1663IMS8#TR参数

参数
最小工作供电电压 -
放大器类型 -
典型供电电流 -
最大工作供电电压 -
安装方式 贴片安装
零件状态 在售
包装方式 散装
